Digital Gap & Step Gauges with flat measuring face Step&Gap Gauge Electronic digital step gap gauge

Digital Gap & Step Gauge are used for checking the mutual position of two adjacent surfaces of vehicles.

Can measure the step between two adjacent surfaces

Portable and easy to operate

Application: speical tool for car repair, measuring car parts, measuring concave and convex, measuring gap, widely used in auto industry.

Technical Data

1). Measuring range: ±10mm

2). Resolution:0.01mm/0.0005in

3). Accuracy:0.01mm

4). Operating Temperature:0°C~40°C

5). Storage temperature :-10°C~60°C Relative humidity:100%

6). power:1.5V LR44 battery

(battery not include for air shipment due to postal regulations)

Please ask any questions before purchase. Thanks for looking!

7) mm and inch switch freely

• Monoblock and Non Monoblock Types
• Hardened Steel construction
• Inside , outside , step measurement
• With Fine adjustment and Locking Screw
• Upper Jaw for inside measurement also available
• Lower Jaws measures both Outside diameters and internal diameters

• Facilitates measurement of gear thickness.
• Mm/inch conversion
• Zero-setting at any position.
• With data output
• Sizes : 1-25mm , 5-50 mm

• Most Stable Microprocessor
• Stainless Steel smooth slides
• 4 Way Measurement Inside, outside, depth, step
• With Thumb lock and Bezel.

• Stable Microprocessor
• Stainless Steel EXTRA smooth slides
• 4 Way Measurement Inside, outside, depth, step
• With Thumb lock and Bezel.
• Extra Smooth

We are passionately engaged in providing a wide assortment of Waterproof Digimatic Vernier to our esteemed clients. These products are widely used in various kinds of industrial purposes depending upon the need of the clients. Our offered products are manufactured by using optimum quality basic material and modern technology at our vendors’ end. In addition to this, these are delivered to the clients within promised timeframe across the nation.

1. Stable Microprocessor

2. IP65 Waterproof Model

3. Stainless steel with Extra Smooth slides

4. With Thumb Lock and Bezel

5. With Dataout put port

6. With Calibration Certificate

7. With 6 Months Guarantee without Abuse .

8. Size Range : 0-150mm , 200 mm , 300mm

9. Least Count : 0.01mm Accuracy : 0.02mm

10. With Depth Gauge bar

Stable Microprocessor

1.    Stainless steel

2.    With Thumb Lock and Bezel

3.    With Calibration Certificate

4.    With 6 Months Guarantee without Abuse

5.    Size Range : 0-150mm , 200 mm , 300mm

6.    Least Count : 0.01mm  Accuracy : 0.02mm

7.    With Depth Gauge Bar

• Monoblock Type
• Single piece construction gives accuracy for longer period of time
• Hardened steel construction
• Extra smooth slides
• 4 Way Measurement Inside, Outside, Depth, Step
• With Fine adjustment and Locking Screw

A Vernier depth gauge is a useful measurement device equipped with two scales, one fixed and one that slides. It can measure extremely precise distances, in some cases to

.02 mm. Anyone doing construction or remodeling work and in need of accurate measurements of the depth of a slot, hole or recess will find a Vernier depth gauge extremely handy

• Robust Stainless Steel construction
• 4 Way Measurement Inside, outside, depth, step
• Golden Dial with black Marking for easier reading
• Adjustable Bezel and Lock

• Robust Stainless Steel construction
• 4 Way Measurement Inside, outside, depth, step
• Golden Dial with black Marking for easier reading
• Adjustable Bezel and Lock
